|Weight Qbiss One B (kg/m²)||21.6||24.1||26.5||27.7||30.1||32.8||36.1||40.9|
|Weight Qbiss One F (kg/m²)||21.4||23.8||26.2||27.4||29.8||32.5||35.8||40.6|
|U Thermal transmittance (W/m²K)*||0.49||0.40||0.33||0.30||0.27||0.24||0.20||0.17|
|Fire resistance class||/||EI 30||EI 90||EI 120||EI 120||EI 120||EI 120||EI 120|
|Weight Qbiss One B Power T (kg/m²)||18.3||20.2||22.0||23.4||24.7||26.7||29.2||32.8|
|Weight Qbiss One F Power T (kg/m²)||18.2||20.0||21.8||23.2||24.5||26.5||29.0||32.6|
|U Thermal transmittance Qbiss One Power T (W/m²K)*||0.45||0.36||0.30||0.28||0.25||0.21||0.19||0.16|
|Fire resistance class Qbiss One Power T||/||/||EI 90||EI 120||EI 120||EI 120||EI 120||EI 120|
|Weight Qbiss One B Power S||20.2||22.5||24.8||26.6||28.2||30.8||33.9||38.5|
|Weight Qbiss One F Power S (kg/m²)||20.0||22.3||24.6||26.4||28.0||30.6||33.8||38.3|
|U Thermal transmittance Qbiss One Power S (W/m²K)*||0.50||0.41||0.34||0.31||0.28||0.24||0.21||0.16|
|Fire resistance class Qbiss One Power S||/||EI 30||EI 90||EI 120||EI 120||EI 120||EI 120||EI 120|
|Insulant core||Non-combustible mineral wool Class A1|
|Rw Sound reduction (EN 10140-3)||30 (-1, 3)|
|Length||530 - 6500 mm|
|Modular width||1000 mm (available from 600 to 1200 mm)|
|External profile||G - smooth|
|Internal profile||g, s, v, v2, m2 - profile|
|Water permeability||Class A (1200 Pa)|
* For specific project data refer to Technical CE specification data and contact Trimo Technical Support.
Calculated according to EN 14509 standard without consideration of longitudinal joint losses.
Qbiss One facade systems have been tested and approved to Factory Mutual (FM 4880, FM 4881) and Loss Prevention Certification Board (LPS 1208), standards to comply with property insurers risk requirements.
Trimo ensures that accurate and comprehensive information is always available because the company knows that the essence of a successful project lies in the detail.
Trimo’s team of experienced specialists ensures precise, timely and quality technical information. A selection of useful information for architects and designers is available on request.
Trimo also welcomes your opinions, observations and questions and will do its best to provide answers as quickly as possible.
For technical information:
For commercial inquiries:
At Trimo, quality and excellent technical characteristics of its products with complete solutions are supported by numerous certificates that help the company fulfil different demands, from business processes to legal restrictions as well as the conditions that are set by insurance companies all over the world.
The acquired and attested certificates for business processes:
For a quality management system according to ISO 9001
For an environment management system according to ISO 14001
For a health and safety system at work according to OHSAS 18001.
See certificates library
